Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados

Nome da marca: Xrido
Número do modelo: Personalizável
Condições de pagamento: Negociável
Informações detalhadas
Certificação:
CE ISO
local de origem:
Henan, China
Inspecção de saída por vídeo:
Fornecido
Relatório de ensaio da máquina:
Fornecido
Componentes essenciais:
PLC, Motor, motor
brand name:
Xrido
Garantia:
1 ano
Material / metal processado:
Aço inoxidável, latão/cobre, liga, aço carbono, alumínio.
Potência (kw):
18.5
Principais pontos de venda:
Multifuntcionais
Aplicação:
Reciclagem de cabos de sucata
Nome:
Máquina de trituração de sucata
Palavra chave:
Linha de trituração de sucata
Produto final:
1-10 cm
Função:
Reciclar o Metal
Voltagem:
380/230/220v
Garantia:
12 meses
Vantagem:
99% de pureza separada
Cores:
Requisitos do cliente
Condição:
Novos
Garantia dos componentes principais:
1 ano
Indústrias aplicáveis:
Lojas de material de construção, lojas de reparação de máquinas, lojas de impressão
Tempo de entrega:
2-32 dias úteis
Destacar:

Triturador de eletrodomésticos sucata

,

Triturador de plástico e metal

,

Triturador de eletrodomésticos usados

Descrição do produto
Scrap Home Appliance Crusher Plastic Crusher Metal Crusher Waste Home Appliance Recycling Machine
Products Description

Waste home appliance plastic recycling equipment, suitable for recycling: refrigerators, washing machines, air conditioners, computers, televisions, waste electronic shells for crushing and processing. It is convenient for recycling and recycling. It is mainly crushed by a special double-axis shredder, and then crushed by a heavy crusher. After the crushing stage, wind equipment and special structures are used for dust removal, and strong magnetic equipment is used to separate the iron-based metals. Then the cleaning, rinsing and drying process is carried out to achieve the complete process of processing waste home appliance plastics. This production line has the characteristics of low energy consumption, large processing capacity, good economy, low maintenance cost, and good treatment effect.

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 0

Application fields of household appliance crusher
1. ‌Recycling of waste household appliances‌
Mainly used for the crushing and disassembly of large household appliances such as refrigerators, washing machines, air conditioners, and televisions, to achieve the separation and recycling of metals (iron, copper, aluminum) and non-metals (plastics, rubber).
By reducing the volume through crushing, it is convenient for subsequent resource classification and transportation.
2. ‌Electronic waste treatment‌
Applicable to electronic waste such as waste computers, printers, and CDs, and extract recyclable metals and plastics after crushing.
Some models can handle electronic components containing hazardous materials (such as circuit boards), which require environmental protection processes.
3. ‌Automobile dismantling industry‌
Crushing metal parts such as automobile shells and wheels is similar to household appliance crushing technology, and some equipment can be used universally.
4. ‌Industrial waste treatment‌
Handling metal scraps, scrap steel, etc. in the industrial field to improve the efficiency of scrap steel smelting.
The double-axis shearing crusher can handle mixed industrial waste such as rubber tires and leather waste.

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 1

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 2
The waste home appliance crusher adopts a unique design. After improvement, the waste home appliance crusher no longer uses blades, but is specially installed with a knife disc and a liner according to the fuselage design structure, which can not only crush the waste home appliances into particles. The paint on the waste home appliances can also be ground off, and then the paint and impurities in the waste home appliance particles are cleaned by the fan and dust collector. The waste home appliance crusher includes TV crusher, refrigerator crusher, washing machine crusher, electric fan crusher, rotor crusher, waste air conditioner, computer crusher, etc., but the purpose is the same, to crush the waste home appliances to satisfy customers!

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 3

Efficiency of separation of metal and plastic in home appliance crusher:

Material Type Separation Technology Recovery Rate Applicable Equipment Example
Refrigerator Metal/Plastic Mechanical Crushing + Magnetic Separation ≥95% Waste Shredder Machine
Aluminum-Plastic Composite Electrostatic Separation 99.8% Aluminum-Plastic Separator
E-waste Copper/Plastic Eddy Current Separation 90%-98% Copper Wire Recycling Machine

Key Notes:

The recovery rates are based on industrial-grade equipment under optimal conditions
Actual efficiency may vary depending on material purity and equipment configuration
Modern separation lines often combine multiple technologies for higher yields

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 4

Process:

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 5

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 6

Features of the waste household appliance crusher:
The waste household appliance crusher has a stable and compact structure, is easy to operate and maintain, and is fed by a conveyor to improve work efficiency and realize automation of operations. The discharge port is equipped with a magnetic separation device to completely separate iron and other impurities, making the best use of materials. The hammer head and lining plate are made of special materials, which have a long machine life and reduce transportation, manpower and other costs. The profit is increased by at least 50%. The crushed materials are clean and bright, which can directly meet the requirements of "fine materials entering the furnace". Users are welcome to visit the company and test the machine on site.
Product Paramenters:
model
voltage
power(kw)
capacity(t/h)
accessory equipment
PSJ-140
380v
132
2-3
Feeding conveyor one

Discharging conveyor one

Iron conveyor one

Impurity conveyor one

Magnetic separation system one

Dust removal system one

Control system one

Intelligent Visual System (Optional) one

Sprinkler system (optional) one
PSJ-200
380v
200
3-5
PSJ-280
380v
280
4-7
PSJ-315
380v
315
5-8
PSJ-450
380v
450
8-12
PSJ-630
10kv
630
10-15
PSJ-750
10kv
750
12-17
PSJ-800
10kv
800
15-20
PSJ-900
10kv
900
20-30
1500HP
10kv
1200
25-40
2000HP
10kv
1500
50-60
3000HP
10kv
2250
60-80
4000HP
10kv
3000
80-100
6000HP
10kv
4420
100-160
8000HP
10kv
6000
160-200
10000HP
10kv
7500
200-26


Case:

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 7

Triturador de plástico e metal para eletrodomésticos sucata, máquina de reciclagem de eletrodomésticos usados 8
